IVO M116NWR7 R4 LCD

Specification

Model P/N:M116NWR7 R4
Brand:IVO
Diagonal Size:11.6"
Resolution:1366(RGB)×768, WXGA 135PPI
Contrast Ratio:800:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:256.125(W)×144(H) mm
Bezel Opening:-
Outline Dim:278.5(H)×168.5(V) ×3(D) mm
Treatment:Antiglare
Luminance:220 cd/m² (Typ.)
View Direction:Symmetry
Response Time:25/35 (Typ./Max.)(Tr+Td)
Operating Mode:IPS, Normally Black, Transmissive
Support Color:262K 50% NTSC
Light Source:WLED , 15K hours , With LED Driver
Designed For:Laptop
Frame Rate:60Hz
Touch Panel:Without
Interface Type:eDP (1 Lane) , eDP1.2 , 30 pins Connector
Power Supply:3.3V (Typ.)
Form Style:Slim (PCBA Flat, T≤3.2mm)
