IVO M101AWAJ R0 LCD

Specification

Model P/N:M101AWAJ R0
Brand:IVO
Diagonal Size:10.1"
Resolution:1280(RGB)×720, WXGA 145PPI
Contrast Ratio:1000:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:223.68(W)×125.82(H) mm
Bezel Opening:226.08(W)×129.02(H) mm
Outline Dim:236.08(H)×140.25(V) ×9.5(D) mm
Treatment:Antiglare, Hard coating (3H)
Luminance:950 cd/m² (Typ.)
View Direction:Symmetry
Response Time:25 (Typ.)(Tr+Td)
Operating Mode:IPS, Normally Black, Transmissive
Support Color:16.7M 75% NTSC
Light Source:WLED [8S4P] , 30K hours , W/O Driver
Weight:350/380g (Typ./Max.)
Designed For:Industrial ，Outdoor High Brightness ，Automotive Display
Frame Rate:60Hz
Touch Panel:Without
Interface Type:LVDS (1 ch, 8-bit) , 40 pins FPC
Power Supply:3.3V (Typ.)
