IVO M084GNS1 R1 LCD panel for Industrial Application

Brand：IVO
Model：M084GNS1 R1
Diagonal Size：8.4 inch
Type：a-Si TFT-LCD, LCM
Pixel Format：800(RGB)×600[SVGA]
Configuration：RGB Vertical Stripe
Active Area：170.4(H)×127.8(V) mm
Outline Dim.：203(H)×142.5(V)×6.2(D) mm
Bezel Area：173.4(H)×131.2(V) mm
Treatment：Antiglare
Luminance：350 cd/m2 (Typ.)
Contrast Ratio：600:1 (Typ.) (TM)
View Direction：12 o'clock
Response Time：16 (Typ.)(Tr+Td)
Viewing Angle：80/80/80/80 (Typ.)(CR≥10)
Operating Mode：TN, Normally White, Transmissive
Support Color：262K/16.7M 45%(CIE1931)
Light Source：WLED[8S4P], 50K hours, With LED Driver
Weight： 200/220g (Typ./Max.)
Designed For： Industrial Application,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 20 pinsLVDS (1 ch, 6/8-bit), Connector
Power Supply：3.3V (Typ.)
Environment： Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C
