Sharp LX055A1BB10 LCD

Specification

Model P/N:LX055A1BB10
Brand:Sharp
Diagonal Size:5.5"
Resolution:1080(RGB)×1920, FHD 403PPI
Brightness:0 cd/m²
Contrast Ratio:1300:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:CG-Silicon, CELL , Q-CUT (Full Cell)
Pixel Format:RGB Vertical Stripe
Active Area:68.04(W)×120.96(H) mm
Bezel Opening:-
Response Time:35 (Max.)(Tr+Td)
Outline Size:69.44(W)×126.86(H) ×0.3(D) mm
Surface:Without Polarizer
Best View on:Symmetry
Display Colors:83% NTSC
Lamp Type:No B/L
Frequency:60Hz
Touch Screen:In-Cell Touch
Panel Weight:5.60g (Typ.)
Application:Mobile Phone
Driver IC:COG Suggest FT8716, FT8736
Glass Depth:0.15+0.15 mm
Transmissivity:3.74% (Typ.)(with Polarizer)
