Samsung LTS180S7-HF1 LCD

Specification

Model P/N:LTS180S7-HF1
Brand:Samsung
Diagonal Size:1.77"
Resolution:128(RGB)×160 115PPI
Contrast Ratio:250 : 1 (Typ.) (TM)
Viewing Angle:45/45/45/15 (Typ.)(CR≥10)
Color Depth:4096
Backlight:3S1P WLED , No Driver
Signal Type:CPU , FPC 19 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:28.032(W)×35.04(H) mm
Bezel Opening:-
Treatment:Hard coating (3H)
Luminance:180 cd/m² (Typ.)
Response:25 (Typ.)(Tr+Td) ms
Good View at:12 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:-
Used for:Mobile Phone
Refresh Rate:-
Touchscreen:Without
Voltage Supply:2.8V (Typ.)
Max Ratings:Storage Temp.: -30 ~ 70 °C Operating Temp.: -20 ~ 60 °C
Outline (mm):33.92×48.24×3.1 (H×V×D)
