Samsung LTN141P1-L02 LCD

Specification

Model P/N:LTN141P1-L02
Brand:Samsung
Diagonal Size:14.1"
Resolution:1400(RGB)×1050, SXGA+ 124PPI
Contrast Ratio:200 : 1 (Typ.) (TM)
Viewing Angle:45/45/15/30 (Typ.)(CR≥10)
Color Depth:262K
Backlight:1 pcs CCFL
Signal Type:LVDS (2 ch, 6-bit) , Connector 20 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:285.6(W)×214.2(H) mm
Bezel Opening:-
Treatment:-
Luminance:150 cd/m² (Typ.)
Response:40 (Typ.)(Tr+Td) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Used for:Laptop
Refresh Rate:60Hz
Touchscreen:-
Voltage Supply:3.3V (Typ.)
Outline (mm):298.5×226.5 (H×V×D)
Outline Shape:Wedge (PCBA Bent, T≥5.2mm)
