TOSHIBA LTM12C505N LCD

Specification

Model P/N:LTM12C505N 5
Brand:TOSHIBA
Diagonal Size:12.1"
Resolution:1024(RGB)×768, XGA 105PPI
Contrast Ratio:150:1 (Min.) (TM)
Viewing Angle:30/30/10/20 (Min.)(CR≥10)
Panel Type:LTPS TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:245.76(W)×184.32(H) mm
Bezel Opening:250.4(W)×188.9(H) mm
Outline Dim:261(H)×199(V) ×5(D) mm
Treatment:Antiglare, Hard coating (3H)
Luminance:150 cd/m² (Typ.)
View Direction:6 o'clock
Response Time:50/50 (Max.)(Tr/Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:262K 48% NTSC
Light Source:CCFL [1 pcs] , W/O Driver
Designed For:Laptop
Frame Rate:60Hz
Touch Panel:Without
Interface Type:LVDS (1 ch, 6-bit) , 20 pins Connector
Power Supply:3.3V (Typ.)
Form Style:-
