TOSHIBA LTM12C275A LCD

Specification

Model P/N:LTM12C275A
Brand:TOSHIBA
Diagonal Size:12.1"
Resolution:800(RGB)×600, SVGA 82PPI
Brightness:250 cd/m² (Typ.)
Contrast Ratio:250:1 (Typ.) (TM)
Viewing Angle:-
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:246(W)×184.5(H) mm
Bezel Opening:249.0(W)×187.5(H) mm
Response Time:50/50 (Max.)(Tr/Td)
Outline Size:290(W)×220(H) ×15(D) mm
Surface:-
Best View on:-
Display Colors:262K
Lamp Type:2 pcs CCFL , 25K hours , Without Driver
Frequency:-
Touch Screen:Without
Panel Weight:840g (Typ.)
Application:Industrial
Signal Interface:Parallel RGB (1 ch, 6-bit) , 30 pins Connector
Input Voltage:5.0V (Typ.)
