Toshiba LTM10C210 LCD panel

Brand：Toshiba Matsushita
Model：LTM10C2102 Compatible
Diagonal Size：10.4 inch
Type：a-Si TFT-LCD, LCM
Pixel Format：640(RGB)×480[VGA]
Configuration：RGB Vertical Stripe
Active Area：211.2(H)×158.4(V) mm
Outline Dim.：265(H)×188.8(V)×12(D) mm
Bezel Area：216.2(H)×163.4(V) mm
Treatment：-
Luminance：400 cd/m2 (Typ.)
Contrast Ratio：250:1 (Typ.) (TM)
View Direction：-
Response Time：50/50 (Max.)(Tr/Td)
Viewing Angle：60/60/50/50 (Typ.)(CR≥10)
Operating Mode：TN, Normally White, Transmissive
Support Color：262K
Light Source：CCFL[2 pcs], 50K hours, W/O Driver
Weight：650g (Typ.)
Designed For： Industrial Application,
Frame Rate：-
Touch Panel：Without
Interface Type： 31 pinsParallel RGB (1 ch, 6-bit), Connector
Power Supply：5.0V (Typ.)(VDD)
Environment：Operating Temperature: 0 ~ 50 °C; Storage Temperature: -20 ~ 60 °C
