Sharp LS055R3SX01(G) LCD

Specification

Model P/N:LS055R3SX01(G)
Brand:Sharp
Diagonal Size:5.5"
Resolution:1536(RGB)×2560 546PPI
Contrast Ratio:1200 : 1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Color Depth:16.7M 70% NTSC
Backlight:8S2P WLED , No Driver
Signal Type:MIPI (4 data lanes) , 32 pins Connector
Panel Type:CG-Silicon, LCM
Pixel Format:RGB Vertical Stripe
Active Area:71.424(W)×119.04(H) mm
Bezel Opening:-
Treatment:-
Luminance:450 cd/m² (Typ.)
Outline(mm):73.824 × 126.44 × 1.4 (H×V×D)
Response:35 (Max.)(Tr+Td) ms
Good View at:Symmetry
Work Mode:New Mode2, Normally Black, Transmissive
Mass:21.1g
Used for:Mobile Phone
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:1.8/5.5/-5.5V (Typ.)(IOVDD/VSP/VSN)
Max Ratings:Storage Temp.: -30 ~ 70 °C Operating Temp.: -20 ~ 60 °C
