Sharp LQ201X3LZ11 LCD

Specification

Model P/N:LQ201X3LZ11
Brand:Sharp
Diagonal Size:20.1"
Resolution:1024(RGB)×768, XGA 63PPI
Contrast Ratio:800:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:408.576(W)×306.432(H) mm
Bezel Opening:414.1(W)×311.44(H) mm
Outline Dim:450.4(H)×340.45(V) ×45.1(D) mm
Treatment:Antiglare (Haze 23%), Hard coating (2H)
Luminance:500 cd/m² (Typ.)
View Direction:Symmetry
Response Time:16/5 (Typ.)(Tr/Td)
Operating Mode:ASV, Normally Black, Transmissive
Support Color:16.7M 74% NTSC
Light Source:CCFL [6 pcs] , 50K hours , With Inverter
Weight:2.48±0.15Kgs
Designed For:TV Sets
Frame Rate:60Hz
Touch Panel:Without
Interface Type:LVDS (1 ch, 8-bit) , 30 pins Connector
Power Supply:5.0V (Typ.)
