LQ150X1LW92 SHARP LCD panel replacement

Brand：SHARP
Model：LQ150X1LW92
Diagonal Size：15.0 inch
Type：a-Si TFT-LCD， LCM
Pixel Format：1024(RGB)×768[XGA]
Configuration： RGB Vertical Stripe
Active Area：304.128(H)×228.096(V) mm
Outline Dim.：326.5(H)×253.5(V)×10.1(D) mm
Bezel Area：307.4(H)×231.3(V) mm
Treatment：Antiglare， Hard coating (3H)
Luminance：-
Contrast Ratio： 1500:1 (Typ.) (TM)
View Direction：Symmetry
Response Time：35 (Typ.)(Tr+Td)
Viewing Angle：85/85/85/85 (Typ.)(CR≥10)
Operating Mode：ASV， Normally Black， Transmissive
Support Color：16.2M 70%(CIE1931)
Light Source：WLED， With LED Driver
Weight： 950g (Max.)
Designed For： Gaming,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 30 pinsLVDS (1 ch， 8-bit)， Connector
Power Supply：3.3V (Typ.)
Environment： Operating Temperature: 0 ~ 60 °C ; Storage Temperature: -25 ~ 65 °C：：
