Sharp LQ150X1LBE8 LCD

Specification

Model P/N:LQ150X1LBE8
Brand:Sharp
Diagonal Size:15.0"
Resolution:1024(RGB)×768, XGA 85PPI
Brightness:280 cd/m² (Typ.)
Contrast Ratio:300:1 (Typ.) (TM)
Viewing Angle:45/45/10/30 (Min.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:304.128(W)×228.096(H) mm
Bezel Opening:307.6(W)×231.6(H) mm
Response Time:10/25 (Typ.)(Tr/Td)
Outline Size:315.8(W)×240.5(H) ×7(D) mm
Surface:Glare (Haze 0%), Hard coating (2H), Antireflection
Best View on:6 o'clock
Display Colors:262K
Lamp Type:1 pcs CCFL , 10K hours , Without Driver
Frequency:60Hz
Touch Screen:Without
Application:Laptop
Signal Interface:LVDS (1 ch, 6-bit) , 30 pins Connector
Input Voltage:3.3V (Typ.)
Shape Style:Wedge (PCBA Bent, T≥5.2mm)
