Sharp LQ0DZA0050 LCD

Specification

Model P/N:LQ0DZA0050 1
Brand:Sharp
Diagonal Size:5.0"
Resolution:1024(RGB)×600, WSVGA 238PPI
Contrast Ratio:450 : 1 (Typ.) (TM)
Viewing Angle:70/70/50/60 (Typ.)(CR≥10)
Color Depth:262K
Backlight:WLED , 10K hours , With LED Driver
Signal Type:LVDS (1 ch, 6-bit) , Connector 30 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:109.1(W)×63.9(H) mm
Bezel Opening:-
Treatment:Glare (Haze 0%), Hard coating (2H)
Luminance:350 cd/m² (Typ.)
Response:30 (Typ.)(Tr+Td) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:67/72g (Typ./Max.)
Used for:MID UMPC
Refresh Rate:-
Touchscreen:4-wire Resistive Touch
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -25 ~ 70 °C Operating Temp.: 0 ~ 60 °C
Outline (mm):119×76.3×5.65 (H×V×D)
