Sharp LQ057Q3DC03A LCD

Specification

Model P/N:LQ057Q3DC03A
Brand:Sharp
Diagonal Size:5.7"
Resolution:320×240(RGB), QVGA 70PPI
Contrast Ratio:350 : 1 (Min.) (TM)
Viewing Angle:80/80/80/65 (Typ.)(CR≥10)
Color Depth:262K
Backlight:WLED , 50K hours , With LED Driver
Signal Type:Parallel RGB (1 ch, 6-bit) , Connector 33 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Horizontal Stripe
Active Area:115.2(W)×86.4(H) mm
Bezel Opening:121.0(W)×92.2(H) mm
Treatment:Glare (Haze 0%), Hard coating (2H)
Luminance:500 cd/m² (Typ.)
Response:30 (Typ.)(Tr+Td) ms
Good View at:12 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:210g (Max.)
Used for:Industrial
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C
Outline (mm):144×104.6×12.8 (H×V×D)
