Sharp LQ039Q2DS02 LCD

Specification

Model P/N:LQ039Q2DS02
Brand:Sharp
Diagonal Size:3.9"
Resolution:320(RGB)×240, QVGA 103PPI
Contrast Ratio:20:1 (Typ.) (RF)
Viewing Angle:-
Color Depth:262K
Backlight:No B/L
Signal Type:Parallel RGB FPC
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:79.2(W)×58.32(H) mm
Bezel Opening:-
Treatment:-
Luminance:-
Outline(mm):92.1 × 71.3 × 2.6 (H×V×D)
Response:-
Good View at:12 o'clock
Work Mode:TN, Normally White, Reflective
Mass:32.0g (Typ.)
Used for:Handheld & PDA
Refresh Rate:60Hz
Touchscreen:Without
Max Ratings:Storage Temp.: -25 ~ 70 °C Operating Temp.: 0 ~ 50 °C
