LQ038Q7DB03 SHARP LCD panel replacement for Handheld & PDA

Panel Brand：SHARP
Panel Model：LQ038Q7DB03
Panel Size：3.8 inch
Panel Type：a-Si TFT-LCD, LCM
Resolution：240(RGB)×320 , QVGA
Pixel Format：RGB Vertical Stripe
Display Area：57.6(W)×76.8(H) mm
Bezel Opening：61.2(W)×80.4(H) mm
Outline Size：69(W)×88.6(H)×3.65(D) mm
Surface：Hard coating (3H)
Brightness：90 cd/m2 (Typ.)
Contrast Ratio：75:1 (Typ.) (TM) 8:1 (Typ.) (RF)
Viewing Angle：40/40/40/40 (Typ.)(CR≥2)
Display Mode：TN, Normally White, Transflective
Best View on：6 o’clock
Response Time：30/50 (Typ.)(Tr/Td)
Display Colors：262K
Lamp Type：WLED, 10K hours, Without Driver
Frequency： 60Hz
Touch Screen：Without
Panel Weight： 42.0g (Typ.)
Application： Handheld & PDA,
Signal Interface： Parallel RGB (1 ch, 6-bit), 61 pins , FPC
Input Voltage：5.0/3.3/15.0/-15.0V (Typ.)(VSHA/VSHD/VDD/VSS)
Environment： Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 70 °C
