LQ036T1DG01 SHARP LCD panel replacement

Manufacturer：SHARP
Model Name：LQ036T1DG01
Screen Size：3.6 inch
Screen Type：LCM,a-Si TFT-LCD
Pixel Number：272(RGB)×480 (WQVGA)
Arrangement：RGB Vertical Stripe
Active Area(mm)：44.472 × 78.48 (H×V)
Outline(mm)： 51.8 × 90 (H×V×D)
Bezel Area(mm)：-
Treatment：Antiglare, Hard coating (2H)
Luminance：410 cd/m2 (Typ.)
Contrast Ratio：300 : 1 (Typ.) (TM)
Viewing Angle：40/60/60/60 (Typ.)(CR≥10)
Response：30/30 (Typ.)(Tr/Td) ms
Good View at：3 o’clock
Work Mode：TN, Normally White, Transmissive
Color Depth：262K 50%(CIE1931)
Backlight：WLED, No Driver
Mass： 35.0g (Typ.)
Used for： Portable Navigation,
Refresh Rate：60Hz
Touchscreen：Embeded (4-wire Resistive)
Signal Type： Parallel RGB + SPI, FPC , 67 pins
Voltage Supply：1.8/2.5V (Typ.)(VDDIO/VCI)
Max. Ratings： Storage Temp.: -30 ~ 85 °COperating Temp.: -10 ~ 70 °C
