LG Display LP173WFG-SPT1 LCD

Specification

Model P/N:LP173WFG-SPT1
Brand:LG Display
Diagonal Size:17.3"
Resolution:1920(RGB)×1080, FHD 127PPI
Contrast Ratio:1000 : 1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Min.)(CR≥10)
Color Depth:16.7M 100% sRGB
Backlight:WLED , 15K hours , With LED Driver
Signal Type:eDP (4 Lanes) , eDP1.4b , HBR2 (5.4G/lane) , Connector 40 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:381.888(W)×214.812(H) mm
Bezel Opening:-
Treatment:Antiglare, Hard coating (3H)
Luminance:300 cd/m² (Typ.)
Response:9 (Typ.)(Tr+Td), 5.8 (Typ.)(G to G), 3 (Typ.)(G to G)(OD) ms
Good View at:Symmetry
Work Mode:IPS, Normally Black, Transmissive
Used for:Laptop ，Gaming
Refresh Rate:165Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Outline (mm):389.89×238.31×3 (H×V×D)
Outline Shape:Slim (PCBA Flat, T≤3.2mm)
