LP156WH3-TPS1 LG Display LCD panel replacement

Manufacturer：LG Display
Model Name：LP156WH3-TPS1 (LGD03F8) 18 Compatible
Screen Size：15.6 inch
Screen Type：LCM ,a-Si TFT-LCD
Pixel Number：1366(RGB)×768 (WXGA)
Arrangement：RGB Vertical Stripe
Active Area(mm)： 344.232 × 193.536 (H×V)
Outline(mm)：359.5 × 223.5× 3.8 (H×V×D)
Bezel Area(mm)： 347.5 × 196.8 (H×V)
Treatment： Glare (Haze 0%), Hard coating (3H)
Luminance：200 cd/m2 (Typ.)
Contrast Ratio：500 : 1 (Typ.) (TM)
Viewing Angle： 40/40/10/30 (Min.)(CR≥10)
Response： 16 (Typ.)(Tr+Td) ms
Good View at： 6 o’clock
Work Mode： TN, Normally White, Transmissive
Color Depth：262K 45%(CIE1931)
Backlight：WLED, 12K hours, With LED Driver
Outline Shape： Flat (PCBA Flat, Depth 3.4~4.0mm)
Used for： Laptop,
Refresh Rate：60Hz
Touchscreen：Without
Signal Type：eDP (1 Lane), Connector, 30 pins
Voltage Supply：3.3V (Typ.)
Max. Ratings：Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
