LG.Philips LP154W01-A5K1 LCD

Specification

Model P/N:LP154W01-A5K1 7
Brand:LG.Philips LCD
Diagonal Size:15.4"
Resolution:1280(RGB)×800, WXGA 98PPI
Contrast Ratio:300 : 1 (Typ.) (TM)
Viewing Angle:45/45/15/35 (Typ.)(CR≥10)
Color Depth:262K 45% NTSC
Backlight:1 pcs CCFL , 10K hours , No Driver
Signal Type:LVDS (1 ch, 6-bit) , Connector 30 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:331.2(W)×207(H) mm
Bezel Opening:335.0(W)×210.7(H) mm
Luminance:150 cd/m² (Typ.)
Response:30 (Typ.)(Tr+Td) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Used for:Laptop
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Outline Shape:Wedge (PCBA Bent, T≥5.2mm)
