LG.Philips LP141X8-A1 LCD

Specification

Model P/N:LP141X8-A1
Brand:LG.Philips LCD
Diagonal Size:14.1"
Resolution:1024(RGB)×768, XGA 91PPI
Contrast Ratio:250 : 1 (Typ.) (TM)
Viewing Angle:45/45/15/35 (Typ.)(CR≥10)
Color Depth:262K 45% NTSC
Backlight:1 pcs CCFL , 10K hours , With Inverter
Signal Type:LVDS (1 ch, 6-bit) , Connector 20 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:285.696(W)×214.272(H) mm
Bezel Opening:288.9(W)×217.5(H) mm
Treatment:Antiglare, Hard coating (3H)
Luminance:170 cd/m² (Typ.)
Response:20/30 (Typ.)(Tr/Td) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Used for:Laptop
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Outline (mm):298.5×239×6 (H×V×D)
Outline Shape:Wedge (PCBA Bent, T≥5.2mm)
