LP133WX3-TLA6 LG Display LCD panel replacement for Laptop

Panel Brand：LG Display
Panel Size：13.3 inch
Resolution：1280(RGB)×800 , WXGA
Display Area：286.08(W)×178.8(H) mm
Outline Size：307.38(W)×203.1(H)×3.75(D) mm
Brightness：330 cd/m2 (Typ.)
Viewing Angle：70/70/60/60 (Typ.)(CR≥10)
Best View on：6 o’clock
Display Colors：262K
Frequency： 60Hz
Shape Style：Flat (PCBA Flat, Depth 3.4~4.0mm)
Panel Model：LP133WX3-TLA6 (APP9CC5)11 Compatible
Panel Type：a-Si TFT-LCD , LCM
Pixel Format： RGB Vertical Stripe
Bezel Opening：289.38(W)×182.5(H) mm
Surface：Glare (Haze 0%), Hard coating, Antireflection
Contrast Ratio：600:1 (Typ.) (TM)
Display Mode： TN, Normally White, Transmissive
Response Time：16 (Typ.)(Tr+Td)
Lamp Type： 9S6P WLED , 10K hours , Without Driver
Touch Screen：Without
Application： Laptop,
Signal Interface： LVDS (1 ch, 6-bit), 30 pins , Connector
Input Voltage： 3.3V (Typ.)
Environment： Operating Temp.: 0 ~ 50 °C ;Storage Temp.: -20 ~ 60 °C
