LP101WSA-TLN1 LG Display LCD panel replacement for Netbook PC

Brand：LG Display
Diagonal Size：10.1 inch
Pixel Format：1024(RGB)×600[WSVGA]
Active Area：222.72(H)×125.28(V) mm
Bezel Area：226.0(H)×128.7(V) mm
Luminance：200 cd/m2 (Typ.)
View Direction：6 o'clock
Viewing Angle：30/30/10/20 (Min.)(CR≥10)
Support Color：262K
Form Style：Wedge (PCBA Bent， Depth ≥5.2mm)
Frame Rate： 60Hz
Model：LP101WSA-TLN1 (LGD0295) 13 Compatible
Type：a-Si TFT-LCD ， LCM
Configuration：RGB Vertical Stripe
Outline Dim.： 235(H)×143(V)×5.2(D)mm
Treatment：Glare (Haze 0%)
Contrast Ratio： 300:1 (Min.) (TM)
Response Time：16 (Typ.)(Tr+Td)
Operating Mode： TN， Normally White， Transmissive
Light Source： WLED， 10K hours ， With LED Driver
Designed For： Netbook PC,
Touch Panel：Without
Interface Type： 40 pinsLVDS (1 ch， 6-bit)， Connector
Power Supply： 3.3V (Typ.)
Environment： Operating Temperature: 0 ~ 50 °C; Storage Temperature: -20 ~ 60 °C
