LG Display LP101WH4-SLAF LCD

Specification

Model P/N:LP101WH4-SLAF
Brand:LG Display
Diagonal Size:10.1"
Resolution:1366(RGB)×768, WXGA 155PPI
Contrast Ratio:800 : 1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Color Depth:16.7M
Backlight:WLED , 12K hours , No Driver
Signal Type:LVDS (1 ch, 8-bit) , Connector
Panel Type:a-Si TFT-LCD, Assembly
Pixel Format:RGB Vertical Stripe
Active Area:222.52(W)×125.11(H) mm
Bezel Opening:-
Luminance:-
Response:25 (Typ.)(Tr+Td) ms
Good View at:Symmetry
Work Mode:IPS, Normally Black, Transmissive
Mass:-
Used for:Pad & Tablet
Refresh Rate:60Hz
Touchscreen:PCAP
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
