LG Display LP101WH4-SLA6 LCD

Specification

Model P/N:LP101WH4-SLA6
Brand:LG Display
Diagonal Size:10.1"
Resolution:1366(RGB)×768, WXGA 155PPI
Contrast Ratio:800 : 1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Color Depth:16.7M
Backlight:6S6P WLED , 12K hours , No Driver
Signal Type:LVDS (1 ch, 8-bit) , 39 pins Connector
Panel Type:a-Si TFT-LCD, Assembly
Pixel Format:RGB Vertical Stripe
Active Area:222.52(W)×125.11(H) mm
Bezel Opening:-
Treatment:-
Luminance:400 cd/m² (Typ.)
Outline(mm):269.37 × 171.97 × 5.8 (H×V×D)
Response:25 (Typ.)(Tr+Td) ms
Good View at:Symmetry
Work Mode:-
Mass:230g (Max.)
Used for:Pad & Tablet
Refresh Rate:60Hz
Touchscreen:PCAP, I²C
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
