LP097X02-SLD5 LG Display LCD panel replacement for Pad & Tablet

Brand：LG Display
Model：LP097X02-SLD510 Compatible
Diagonal Size：9.7 inch
Type：a-Si TFT-LCD, LCM
Pixel Format：1024(RGB)×768[XGA]
Configuration：RGB Vertical Stripe
Active Area：196.608(H)×147.456(V) mm
Outline Dim.：210.53(H)×166.53(V)×5.82(D) mm
Bezel Area：201.40(H)×152.26(V) mm
Treatment：Glare (Haze 0%), Hard coating (3H)
Luminance：400 cd/m2 (Typ.)
Contrast Ratio：600:1 (Typ.) (TM)
View Direction：Symmetry
Response Time：30 (Typ.)(Tr+Td)
Viewing Angle：89/89/89/89 (Typ.)(CR≥10)
Operating Mode：IPS, Normally Black, Transmissive
Support Color：262K
Light Source：WLED[6S6P], 10K hours, W/O Driver
Weight： 160g (Max.)
Designed For： Pad & Tablet,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 30 pinsLVDS (1 ch, 6-bit), Connector
Power Supply：3.3V (Typ.)
Environment： Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
