LMS430HF20 Samsung LCD panel replacement

Brand：SAMSUNG
Model：LMS430HF20
Diagonal Size：4.3 inch
Type：a-Si TFT-LCD, LCM
Pixel Format：480×272(RGB)[WQVGA]
Configuration：RGB Horizontal Stripe
Active Area：95.04(H)×53.856(V) mm
Outline Dim.：105.5(H)×67.2(V) mm
Bezel Area：96.44(H)×55.236(V) mm
Treatment：-
Luminance：500 cd/m2 (Typ.)
Contrast Ratio：900:1 (Typ.) (TM)
View Direction：Symmetry
Response Time：17/15 (Typ.)(Tr/Td)
Viewing Angle：70/70/70/70 (Typ.)(CR≥10)
Operating Mode：VA, Normally Black, TMR
Support Color：16.7M 50%(CIE1931)
Light Source：WLED[10S1P], W/O Driver
Weight：45.0g (Typ.)
Designed For： Portable Navigation, Pocket TV, MP4 PMP,
Frame Rate： 60Hz
Touch Panel：Without
Interface Type： 40 pinsParallel RGB (1 ch, 8-bit), FPC
Power Supply：2.5/3.3V (Typ.)(VDD)
Environment：Operating Temperature: -20 ~ 60 °C; Storage Temperature: -40 ~ 85 °C
