Samsung LMS430HF07 LCD

Specification

Model P/N:LMS430HF07
Brand:Samsung
Diagonal Size:4.3"
Resolution:480×272(RGB), WQVGA 128PPI
Contrast Ratio:300:1 (Typ.) (TM)
Viewing Angle:60/55/55/50 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Horizontal Stripe
Active Area:95.04(W)×53.856(H) mm
Bezel Opening:-
Outline Dim:105.5(H)×67.2(V) ×3.1(D) mm
Treatment:-
Luminance:200 cd/m² (Typ.)
View Direction:12 o'clock
Response Time:20 (Typ.)(Tr+Td)
Operating Mode:TN, Normally White, TMR
Support Color:262K 48% NTSC
Light Source:WLED [10S1P] , W/O Driver
Weight:39.0/44.0g (Typ./Max.)
Designed For:Portable Navigation ，MP3 PMP
Frame Rate:60Hz
Touch Panel:Without
Interface Type:Parallel RGB (1 ch, 6-bit) + SPI , 45 pins FPC
Power Supply:3.3/3.3V (Typ.)(VCC/VCI)
