Sharp LM32019T LCD

Specification

Model P/N:LM32019T
Brand:Sharp
Diagonal Size:5.7"
Resolution:320×240, QVGA 70PPI
Contrast Ratio:6:1 (Typ.) (TM)
Viewing Angle:40/40/25/40 (Typ.)(CR≥2)
Panel Type:STN-LCD, LCM
Pixel Format:Rectangle
Active Area:115.17(W)×86.37(H) mm
Bezel Opening:121.0(W)×91.6(H) mm
Outline Dim:166(H)×109(V) ×7.5(D) mm
Treatment:-
Luminance:100 cd/m² (Typ.)
View Direction:-
Response Time:190/210 (Typ.)(Tr/Td)
Operating Mode:STN, Blue mode (Negative), Transmissive
Support Color:Monochrome
Light Source:CCFL [1 pcs] , 15K hours , W/O Driver
Weight:160g (Typ.)
Designed For:Industrial
Frame Rate:-
Touch Panel:Without
Interface Type:Parallel Data (1ch, 4-bit) , 12 pins FPC
Power Supply:5.0V (Typ.)
