LG.Philips LM150X06-B4 LCD

Specification

Model P/N:LM150X06-B4
Brand:LG.Philips LCD
Diagonal Size:15.0"
Resolution:1024(RGB)×768, XGA 85PPI
Contrast Ratio:400:1 (Typ.) (TM)
Viewing Angle:65/65/45/55 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:304.128(W)×228.096(H) mm
Bezel Opening:307.4(W)×231.3(H) mm
Outline Dim:331.3(H)×257.9(V) ×11.5(D) mm
Treatment:Antiglare, Hard coating (3H)
Luminance:230 cd/m² (Typ.)
View Direction:6 o'clock
Response Time:10/20 (Typ.)(Tr/Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:262K
Light Source:CCFL [2 pcs] , 40K hours , W/O Driver
Weight:1.00Kgs (Typ.)
Designed For:Desktop Monitor
Frame Rate:70Hz
Touch Panel:Without
Interface Type:LVDS (1 ch, 6-bit) , 20 pins Connector
Power Supply:3.3V (Typ.)
