LG.Philips LH200Q04-TJ01 LCD

Specification

Model P/N:LH200Q04-TJ01
Brand:LG.Philips LCD
Diagonal Size:2.0"
Resolution:240(RGB)×320, QVGA 199PPI
Contrast Ratio:300:1 (Typ.) (TM)
Viewing Angle:55/55/60/40 (Typ.)(CR≥10)
Panel Type:LTPS TFT-LCD, CELL , Full Cell
Pixel Format:RGB Vertical Stripe
Active Area:30.6(W)×40.8(H) mm
Bezel Opening:-
Outline Dim:34.7(H)×61(V) ×1.33(D) mm
Treatment:Hard coating (2H)
Luminance:0 cd/m²
View Direction:12 o'clock
Response Time:25 (Typ.)(Tr+Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:262K 50% NTSC
Light Source:No B/L
Weight:4.90g (Typ.)
Designed For:Mobile Phone
Frame Rate:60Hz
Touch Panel:Without
Interface Type:CPU
Power Supply:2.6/2.8V (Typ.)(VCC1/VCC2)
Plate Thickness:0.45+0.45 mm
Transmittance:5.3% (Typ.)(with Polarizer)
D-IC Detail:COG Suggest uPD161802 + uPD161964
