LG.Philips LH177J01-TH02 LCD

Specification

Model P/N:LH177J01-TH02
Brand:LG.Philips LCD
Diagonal Size:1.77"
Resolution:128(RGB)×160 115PPI
Contrast Ratio:300:1 (Typ.) (TM)
Viewing Angle:45/45/35/15 (Min.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Full Cell
Pixel Format:RGB Vertical Stripe
Active Area:28.032(W)×35.04(H) mm
Bezel Opening:-
Outline Dim:32(H)×43.94(V) ×0.8(D) mm
Treatment:-
Luminance:0 cd/m²
View Direction:12 o'clock
Response Time:25 (Typ.)(Tr+Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:50% NTSC
Light Source:No B/L
Weight:2.50±0.25g
Designed For:Mobile Phone
Frame Rate:-
Touch Panel:Without
Plate Thickness:0.40+0.40 mm
Transmittance:16% (Typ.)(without Polarizer)
D-IC Detail:COG Suggest S6D0123
