LG.Philips LH177J01-TD01 LCD

Specification

Model P/N:LH177J01-TD01
Brand:LG.Philips LCD
Diagonal Size:1.77"
Resolution:128(RGB)×160 115PPI
Contrast Ratio:350 : 1 (Typ.) (TM)
Viewing Angle:45/45/35/15 (Typ.)(CR≥10)
Color Depth:262K 47% NTSC
Backlight:1S2P WLED
Signal Type:CPU , FPC 35 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:28.032(W)×35.04(H) mm
Bezel Opening:-
Treatment:Hard coating (2H)
Luminance:200 cd/m² (Min.)
Response:25 (Max.)(Tr+Td) ms
Good View at:12 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:6.00g (Typ.)
Used for:Mobile Phone
Refresh Rate:-
Touchscreen:Without
Voltage Supply:2.8V (Typ.)
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
Outline (mm):33.9×45.94×2.15 (H×V×D)
