LG.Philips LP171WU1-A4 LCD

Specification

Model P/N:LP171WU1-A4
Brand:LG.Philips LCD
Diagonal Size:17.1"
Resolution:1920(RGB)×1200, WUXGA 132PPI
Contrast Ratio:350:1 (Min.) (TM)
Viewing Angle:65/65/50/50 (Min.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:367.2(W)×229.5(H) mm
Bezel Opening:370.6(W)×232.9(H) mm
Outline Dim:382.7(H)×267.2(V) ×6.6(D) mm
Treatment:Antiglare, Hard coating (3H)
Luminance:190 cd/m² (Typ.)
View Direction:-
Response Time:25 (Typ.)(Tr+Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:262K 45% NTSC
Light Source:CCFL [1 pcs] , 10K hours , W/O Driver
Designed For:Laptop
Frame Rate:60Hz
Touch Panel:Without
Interface Type:LVDS (2 ch, 6-bit) , 30 pins Connector
Power Supply:3.3V (Typ.)
Form Style:Wedge (PCBA Bent, T≥5.2mm)
