Sharp LM64C35P LCD

Specification

Model P/N:LM64C35P
Brand:Sharp
Diagonal Size:10.4"
Resolution:640(RGB)×480, VGA 76PPI
Brightness:70 cd/m² (Typ.)
Contrast Ratio:30:1 (Typ.) (TM)
Viewing Angle:-
Panel Type:CSTN-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:211.2(W)×158.4(H) mm
Bezel Opening:215.2(W)×162.4(H) mm
Response Time:220/80 (Typ.)(Tr/Td)
Outline Size:242.5(W)×179.4(H) ×11.5(D) mm
Surface:-
Best View on:-
Display Colors:Color
Lamp Type:1 pcs CCFL , Without Driver
Frequency:-
Touch Screen:Without
Panel Weight:500g (Typ.)
Application:Industrial
Signal Interface:Parallel Data (1ch, 8-bit) , 31 pins Connector
Input Voltage:5.0V (Typ.)
