LC320EUN-SDV1 LG Display LCD panel replacement for TV Sets

Panel Brand：LG Display
Panel Model：LC320EUN-SDV1
Panel Size：31.5 inch
Panel Type：a-Si TFT-LCD, LCM
Resolution：1920(RGB)×1080 , FHD
Pixel Format：RGB Vertical Stripe
Display Area：698.4(W)×392.85(H) mm
Bezel Opening：705.4(W)×400.0(H) mm
Outline Size：735.4(W)×433(H) mm
Surface：Antiglare (Haze 10%), Hard coating (3H)
Brightness：360 cd/m2 (Typ.)
Contrast Ratio：1400:1 (Typ.) (TM)
Viewing Angle：89/89/89/89 (Min.)(CR≥10)
Display Mode：S-IPS, Normally Black, Transmissive
Best View on：Symmetry
Response Time：6 (Typ.)(G to G)
Display Colors：16.7M 68%(CIE1931)
Lamp Type：WLED, 50K hours, With LED Driver
Frequency： 60Hz
Touch Screen：Without
Panel Weight： 6.00/6.60Kgs (Typ./Max.)
Application： TV Sets,
Signal Interface： LVDS (2 ch, 8-bit), 51 pins , Connector
Input Voltage：12.0V (Typ.)
Environment： Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
