LC320DXE-FGA4 LG Display LCD panel replacement

Manufacturer：LG Display
Model Name：LC320DXE-FGA4
Screen Size：31.5 inch
Screen Type：LCM ,a-Si TFT-LCD
Pixel Number：1366(RGB)×768 (WXGA)
Arrangement：RGB Vertical Stripe
Active Area(mm)： 697.685 × 392.256 (H×V)
Outline(mm)：730.9 × 429.8× 42 (H×V×D)
Bezel Area(mm)： 700.6 × 396.5 (H×V)
Treatment： Antiglare (Haze 1%), Hard coating (3H)
Luminance：300 cd/m2 (Typ.)
Contrast Ratio：1200 : 1 (Typ.) (TM)
Viewing Angle： 89/89/89/89 (Min.)(CR≥10)
Response： 7 (Typ.)(G to G) ms
Good View at： Symmetry
Work Mode： IPS, Normally Black, Transmissive
Color Depth：16.7M 68%(CIE1931)
Backlight：WLED, 30K hours, No Driver
Mass： 3.70/3.90Kgs (Typ./Max.)
Used for： TV Sets,
Refresh Rate：60Hz
Touchscreen：Without
Signal Type：LVDS (1 ch, 8-bit), Connector, 30 pins
Voltage Supply：12.0V (Typ.)
Max. Ratings：Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
