BOE LC270LF4F01 LCD

Specification

Model P/N:LC270LF4F01
Brand:BOE
Diagonal Size:27.0"
Resolution:1920(RGB)×1080, FHD 81PPI
Contrast Ratio:1100:1 (Typ.) (TM)
Viewing Angle:89/89/89/89 (Typ.)(CR≥10)
Panel Type:Oxide TFT-LCD, CELL , FOB
Pixel Format:RGB Vertical Stripe
Active Area:597.888(W)×336.312(H) mm
Bezel Opening:-
Outline Dim:606.488(H)×348.812(V) ×1.04(D) mm
Treatment:Antiglare (Haze 25%), Hard coating (3H)
Luminance:0 cd/m²
View Direction:Symmetry
Response Time:7.5 (Typ.)(G to G)
Operating Mode:FFS, Normally Black, Transmissive
Support Color:16.7M 72% NTSC
Light Source:No B/L
Weight:-
Designed For:Desktop Monitor ，Gaming
Frame Rate:165Hz
Touch Panel:Without
Interface Type:LVDS (4 ch, 8-bit) , 61 pins Connector
Power Supply:12.0V (Typ.)
Plate Thickness:0.40+0.40 mm
Transmittance:5.3% (Typ.)(with Polarizer)
D-IC Detail:COF Built-in 8 source chips
