LG Display LC150X01-SL01 LCD panel

Brand：LG Display
Model：LC150X01-SL01
Diagonal Size：15.0 inch
Type：a-Si TFT-LCD, LCM
Pixel Format：1024(RGB)×768[XGA]
Configuration：RGB Vertical Stripe
Active Area：304.128(H)×228.096(V) mm
Outline Dim.：332.8(H)×262.8(V)×22.7(D) mm
Bezel Area：308.2(H)×232.2(V) mm
Treatment：Antiglare (Haze 25%), Hard coating (3H)
Luminance：430 cd/m2 (Typ.)
Contrast Ratio：450:1 (Typ.) (TM)
View Direction：Symmetry
Response Time：12/13 (Typ.)(Tr/Td)
Viewing Angle：89/89/89/89 (Typ.)(CR≥10)
Operating Mode：S-IPS, Normally Black, Transmissive
Support Color：16.7M 70%(CIE1931)
Light Source：CCFL[6 pcs], 50K hours, W/O Driver
Weight： 2.10Kgs (Typ.)
Designed For： TV Sets,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 20 pinsLVDS (1 ch, 8-bit), Connector
Power Supply：12.0V (Typ.)
Environment： Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
