LG.Philips LB070W02-TME2 LCD

Specification

Model P/N:LB070W02-TME2
Brand:LG.Philips LCD
Diagonal Size:7.0"
Resolution:480(RGB)×234 76PPI
Contrast Ratio:400:1 (Typ.) (TM)
Viewing Angle:65/65/45/55 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:154.08(W)×86.58(H) mm
Bezel Opening:-
Outline Dim:164.9(H)×100(V) ×6(D) mm
Treatment:Antiglare
Luminance:220 cd/m² (Typ.)
View Direction:6 o'clock
Response Time:10/20 (Typ.)(Tr/Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:Full color
Light Source:CCFL [1 pcs] , 20K hours , W/O Driver
Weight:170g (Typ.)
Designed For:Portable DVD Player ，Video Door Phone ，Digital Photo Frame
Frame Rate:-
Touch Panel:Without
Interface Type:TFT Specific Analog RGB , 26 pins FPC
Power Supply:5.0/5.0/16.5/-10.0V (Typ.)(VDD1/VDD2/VGH/VGL)
