LG.Philips LB065W01-B11B LCD

Specification

Model P/N:LB065W01-B11B
Brand:LG.Philips LCD
Diagonal Size:6.5"
Resolution:400(RGB)×234 71PPI
Contrast Ratio:400 : 1 (Typ.) (TM)
Viewing Angle:65/65/50/65 (Typ.)(CR≥10)
Color Depth:Full color
Backlight:1 pcs CCFL , 20K hours , No Driver
Signal Type:TFT Specific Analog RGB , FPC 32 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:143.4(W)×79.326(H) mm
Bezel Opening:147.6(W)×82.9(H) mm
Treatment:Antiglare
Luminance:450 cd/m² (Typ.)
Response:10/30 (Typ.)(Tr/Td) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:165g (Typ.)
Used for:Automotive Display ，Digital Photo Frame ，Portable DVD Player ，Video Door Phone
Refresh Rate:-
Touchscreen:Without
Voltage Supply:5/13/5/-10/-10.9/-16V (Typ.)(VSH/VGH/VGLAC/VGLDC/VCC/VSS)
Max Ratings:Storage Temp.: -40 ~ 85 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.0G (19.6 m/s²)
Outline (mm):157.2×89.7×13.8 (H×V×D)
