LG.Philips LB050WQ3-TD04 LCD

Specification

Model P/N:LB050WQ3-TD04
Brand:LG.Philips LCD
Diagonal Size:5.0"
Resolution:480×272(RGB), WQVGA 110PPI
Brightness:400 cd/m² (Typ.)
Contrast Ratio:500:1 (Typ.) (TM)
Viewing Angle:65/65/50/60 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Horizontal Stripe
Active Area:110.736(W)×62.424(H) mm
Bezel Opening:-
Response Time:25 (Typ.)(Tr+Td)
Best View on:6 o'clock
Display Colors:16.7M
Lamp Type:WLED , Without Driver
Frequency:60Hz
Touch Screen:-
Panel Weight:-
Application:Portable Navigation ，MP3 PMP
Signal Interface:Parallel RGB (1 ch, 8-bit) FPC
