Kyocera KHB065HV1BD-M10 LCD

Specification

Model P/N:KHB065HV1BD-M10
Brand:Kyocera
Diagonal Size:6.5"
Resolution:640(RGB)×240, HVGA 105PPI
Contrast Ratio:15:1 (Typ.) (TM) 5:1 (Typ.) (RF)
Viewing Angle:50/50/30/40 (Typ.)(CR≥2)
Panel Type:CSTN-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:153.58(W)×57.58(H) mm
Bezel Opening:-
Luminance:-
View Direction:-
Response Time:200/150 (Typ.)(Tr/Td)
Operating Mode:STN, Normally Black, Transflective
Support Color:Color
Light Source:CCFL [1 pcs]
Weight:-
Designed For:Industrial
Frame Rate:-
Touch Panel:Without
Interface Type:Parallel Data (1ch, 8-bit) , 18 pins Connector
Power Supply:3.3V (Typ.)
