BOE HV230FH2-600 LCD

Specification

Model P/N:HV230FH2-600
Brand:BOE
Diagonal Size:23.0"
Resolution:1920(RGB)×1080, FHD 95PPI
Brightness:0 cd/m²
Contrast Ratio:1000:1 (Typ.) (TM)
Viewing Angle:89/89/89/89 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , FOB
Pixel Format:RGB Vertical Stripe
Active Area:509.184(W)×286.416(H) mm
Bezel Opening:-
Response Time:14 (Typ.)(G to G)
Outline Size:525.5(W)×301.5(H) mm
Surface:Clear
Best View on:Symmetry
Display Colors:16.7M
Lamp Type:No B/L , Without Driver
Frequency:60Hz
Touch Screen:Without
Panel Weight:660g (Typ.)
Application:Digital Signage ，Transparent Display
Signal Interface:LVDS (2 ch, 8-bit) , 30 pins Connector
Input Voltage:5.0V (Typ.)
Driver IC:COFBuilt-in 6 source + 3 gate chips
Glass Depth:-
Transmissivity:4.3% (Typ.)(with Polarizer)
