HYDIS HV070WS1-D01 LCD

Specification

Model P/N:HV070WS1-D01
Brand:HYDIS
Diagonal Size:7.0"
Resolution:1024(RGB)×600, WSVGA 169PPI
Brightness:0 cd/m²
Contrast Ratio:800:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Full Cell
Pixel Format:RGB Vertical Stripe
Active Area:153.6(W)×90(H) mm
Bezel Opening:-
Response Time:50 (Typ.)(Tr+Td)
Outline Size:161.45(W)×97.76(H) ×0.6(D) mm
Surface:-
Best View on:Symmetry
Display Colors:16.7M 52% NTSC
Lamp Type:No B/L
Frequency:60Hz
Touch Screen:Without
Panel Weight:-
Application:Pad & Tablet ，Portable Navigation ，Digital Photo Frame ，Portable DVD Player ，MID UMPC
Signal Interface:LVDS
Driver IC:COG Suggest NT52002BH + NT51008H
Glass Depth:0.30+0.30 mm
Transmissivity:5.5% (Typ.)(with Polarizer)
