HYUNDAI HT15X22-300 LCD

Specification

Model P/N:HT15X22-300
Brand:HYUNDAI
Diagonal Size:15.0"
Resolution:1024(RGB)×768, XGA 85PPI
Contrast Ratio:300:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:304.128(W)×228.096(H) mm
Bezel Opening:308.8(W)×232.7(H) mm
Outline Dim:350(H)×266.5(V) ×23(D) mm
Treatment:-
Luminance:260 cd/m² (Typ.)
View Direction:Symmetry
Response Time:35 (Typ.)(Tr+Td)
Operating Mode:U-FFS, Normally Black, Transmissive
Support Color:16.7M 61% NTSC
Light Source:CCFL [4 pcs] , 35K hours , Optional
Weight:1.50Kgs (Max.)
Designed For:Desktop Monitor
Frame Rate:60Hz
Touch Panel:Without
Interface Type:TTL (2 ch, 8-bit) , 80 pins Connector
Power Supply:5.0V (Typ.)
