HYUNDAI HT15X22-200 LCD

Specification

Model P/N:HT15X22-200
Brand:HYUNDAI
Diagonal Size:15.0"
Resolution:1024(RGB)×768, XGA 85PPI
Brightness:260 cd/m² (Typ.)
Contrast Ratio:300:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:304.128(W)×228.096(H) mm
Bezel Opening:308.8(W)×232.7(H) mm
Response Time:35 (Typ.)(Tr+Td)
Outline Size:350(W)×266.5(H) ×17.7(D) mm
Surface:-
Best View on:Symmetry
Display Colors:16.7M 61% NTSC
Lamp Type:4 pcs CCFL , 35K hours , Without Driver
Frequency:60Hz
Touch Screen:Without
Panel Weight:1.50Kgs (Max.)
Application:Desktop Monitor
Signal Interface:TTL (2 ch, 8-bit) , 80 pins Connector
Input Voltage:5.0V (Typ.)(VDD)
