HannStar HSD150MX17-A00 LCD

Specification

Model P/N:HSD150MX17-A00
Brand:HannStar
Diagonal Size:15.0"
Resolution:1024(RGB)×768, XGA 85PPI
Brightness:250 cd/m² (Typ.)
Contrast Ratio:600:1 (Typ.) (TM)
Viewing Angle:60/60/40/50 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:304.128(W)×228.096(H) mm
Bezel Opening:307.4(W)×231.3(H) mm
Response Time:16 (Typ.)(Tr+Td)
Outline Size:326.5(W)×253.5(H) ×11.1(D) mm
Surface:Antiglare, Hard coating (3H)
Best View on:6 o'clock
Display Colors:16.2M 68% NTSC
Lamp Type:2 pcs CCFL , 30K hours , Without Driver
Frequency:75Hz
Touch Screen:Without
Panel Weight:925/955g (Typ./Max.)
Application:Desktop Monitor
Signal Interface:LVDS (1 ch, 8-bit) , 20 pins Connector
Input Voltage:3.3V (Typ.)
