HannStar HSD123JPW3-A11 LCD

Specification

Model P/N:HSD123JPW3-A11
Brand:HannStar
Diagonal Size:12.3"
Resolution:1920(RGB)×720 167PPI
Contrast Ratio:1500 : 1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Color Depth:16.7M 75% NTSC
Backlight:11S4P WLED , 30K hours , No Driver
Signal Type:LVDS (2 ch, 8-bit) , Connector 50 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:292.032(W)×109.512(H) mm
Bezel Opening:-
Treatment:Glare (Haze 0%), Hard coating
Luminance:1000 cd/m² (Typ.)
Response:25 (Typ.)(Tr+Td) ms
Good View at:Symmetry
Work Mode:IPS Pro, Normally Black, Transmissive
Mass:348/383g (Typ./Max.)
Used for:Outdoor High Brightness ，Automotive Display
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²)
Outline (mm):302×125.4×9.8 (H×V×D)
